Parker

2-Way Solenoid Valve Parker Ø 1/4" 230V 9W Orifice Ø 2.5mm

Item Number: 632017-22

2-way PARKER solenoid valve 1/4-1/4 inch bsp 220v (complete)
  • 2-way PARKER solenoid valve 1/4-1/4 inch bsp 220v (complete)
RRP $129.95 Save $20.95 Your Price $109
4 payments of $27.25
ZipMoney Logo
Own it now, pay later

In stock

Shipping Estimate

Need Help? Contact Us

Description

2-Way Solenoid Valve Parker Ø 1/4" 230V 9W Orifice Ø 2.5mm

This solenoid valve controls water flow in espresso machines, opening and closing electronically to regulate brewing cycles and prevent backflow. Compatible with Brasilia, Cime, ECM, Faema, Futurmat-Ariete, Gaggia, Italcrem, La San Marco, La Spaziale, Lavazza, Mairali, Nuova Simonelli, Parker, Pavoni, Saeco, Vibiemme, Victoria Arduino, and Visacrem machines.

This valve features Viton sealing and is made in Italy. The 2.5mm orifice handles maximum pressure up to 10 bar with a fluid temperature range of -10°C to +140°C.

Specifications

  • Voltage: 230V
  • Frequency: 50/60Hz
  • Power: 9W
  • Thread size: 1/4" BSP F×F
  • Orifice diameter: 2.5mm
  • Maximum pressure: 10 bar
  • Sealing material: Viton
  • Fluid temperature range: -10°C to +140°C
  • Coil: ZB09
  • Country of origin: Italy

Always verify compatibility with your machine's user manual before purchasing.

Compatible Part Numbers

Also known by the following manufacturer part numbers

04100012Nuova Simonelli 04100012Victoria Arduino 04100022Nuova Simonelli 04100022Victoria Arduino 04100029Nuova Simonelli 0611/060113Futurmat-Ariete 0611/060113Italcrem 0611/060113Mairali 0611/060113Visacrem 06478Spaziale 10061851Lavazza 108035San Marco 108035CSan Marco 1120310LF 1120354LF 370.067Fast Ricambi 370.083Fast Ricambi 370.546Fast Ricambi 397462Parker 397463Parker 397497Parker 451203Pavoni 451272Pavoni 8F139De Vecchi Giuseppe CCEELE0090San Marco CCEELE0100San Marco ELETELE2VAU2Vibiemme VE146V+ZB09Parker VE146VZB09Parker WGADM2115Gaggia WGADM2115Saeco

To fit machines from these brands

Brasilia Cime ECM Faema Futurmat-Ariete Gaggia (home) Gaggia (commercial) Italcrem La San Marco La Spaziale Lavazza Mairali Nuova Simonelli Parker Pavoni (home) Pavoni (commercial) Saeco Vibiemme (home) Vibiemme (commercial) Victoria Arduino Visacrem

Browse all Solenoids on CoffeeParts.

Specifications
Brand Parker
Warranty 1 Year
Returns Change of Mind Not Available
Solenoid Type 2-Way
Solenoid Part Complete
